PASSIVSINE®
Passive Harmonic Filter

The PassivSine® filter provides engineers with a ready-to-use standard solution for what was previously a very challenging engineering problem. It represents the most cost-effective solution for filtering harmonics generated by 6-pulse static converters (frequency converters, uninterruptible power supplies, rectifiers, battery chargers, etc.).

    Standards:
    • IEC 61000-3-4
    • IEC 61000-3-12
    • CEI 61800-3
    • IEEE-519

    Description

    The PassivSine® filter is a purely passive device consisting of a main filtering reactance combined with a relatively small capacitor bank and a line reactor. Its innovative design reduces all major harmonic currents generated by variable speed drives and other static converters with a 6-pulse input rectifier. The resulting total harmonic distortion of the current (THDI) is reduced to less than 8%.

    It has been designed to meet the strict limits of IEEE Std 519 with high efficiency, and with greatly reduced cost and dimensions.

    The PassivSine® filter is connected in series with the static converter to be filtered (frequency converter, uninterruptible power supply, rectifier, charger, etc.). For this purpose, its rating must be carefully chosen so that it is always higher than the maximum effective current (I-RMS max) drawn by the static converter. The filter’s efficiency range is between 40% and 100% of its rated load.

    Advantages

    • Reduction of current waveform distortion flowing back into the grid and the rest of the installation.

    • Compliance with standards IEC 61000-3-4, IEC 61000-3-12, CEI 61800-3, and IEEE-519.

    • Limits current transients, preventing damage to the converter and unintended tripping of protections, caused by induced transient overvoltages, which affect production processes.

    Characteristics

    Main Features:
    Nominal voltage 400V
    Frequency 50 Hz
    Nominal current In see reference table
    Overload 1.5 In for 1 minute
    Residual THD I approximately 8%
    Voltage drop at In max. 2%
    Isolation Voltage 690V
    Impulse withstand voltage Uimp
    Constructive characteristics
    Degree of protection IP 42
    Color RAL 7035
    Degree of Mechanical Resistance IK10
    Temperature Control by thermostat
    Auxiliary Power Supply 230V AC – 50 Hz
    Dimensions
    Height 2140 mm
    Depth 600 mm
    Widths 600 mm, 700 mm, 900 mm, 1600 mm (selon référence)
